DBMIS6E After sales of electric energy meter system

DBMIS6E After sales of electric energy meter system(Email:tawangyue@163.com)
CHAPTER Ⅰ  SYSTEM BRIEF INTRODUCTION


The system is a electricity sales management software, which is developed for power supply department using prepaid meter. The system has complete functions, friendly interface, clear configuration, which is easy to operate and a powerful tool for popularizing the prepaid meter.


11.1 Outline of system


The software and hardware of the sales system consist of a prepaid meter, a IC card reader-writer, IC cards and computer terminal management system.


:About prepaid meter

Prepaid meter is a kind of static meter of high precision and long life, guaranteeing long time stability in measuring precision.


:About read-writer

Minghua RD series of touched IC card reader-writer: reader-writer is frequently used during sales electricity, commanding stable quality.
Reader-writer is connected to serial port with a serial port data wire. Data transmitting speed (baud rate) is 9600bps. After power on, the indicator light indicates when the reader-writer works.


:About IC card

It employs a standard encrypted IC card. The IC card has the data security reinforce function, which is reliable, commonly used and low-cost. It is easy to be adopted at large scale.


:About management software

The management software is developed based on 32 bit in Windows operating system, with Microsoft’s MDAC data accessing assembly itself, running at Chinese version of MS Window98SE/2000 and English version of Window XP.
If screen shows abnormally when system runs, please insure that system’s display color at least be set up at 16 bit over resolution of 800*600 (32 bit real multicolor 1024*768 better).


8. Other system function

Apart from extraordinary task processing capability, it is at good at statistical analysis, providing comprehensive statistical data for analysis and decision-making.

8. System authority

System provides a rigid management of operation authority, a basic data record function of convenience and standard, a perfect function of data backup, modification and restoration. All this makes system safe and reliable.

8. Artistic system interface

System provides comfortable interface. Each step has corresponding prompt. Windows’ and menus’ design are simple and clear.
